SKU: AP-Z217
2U monitor panel for listening to any of 10 speaker channels through a built-in loudspeaker, with five-level LED dB metering and a 10-position channel selector.
The AP-Z217 is the ten-channel monitor panel in AVTRON's control room range, for systems where 16 channels is more than the site needs.
A 10-position selector switch picks the channel and a 500mW full-range monitor speaker reproduces it, with five-level LED metering giving a visual reference for level. Taking 100V or 70V audio from the speaker lines means the panel reports what is actually reaching the speakers.
Controls are deliberately minimal — monitor volume, channel select and power — so an operator checks a zone in seconds without navigating a menu.
Response covers 100Hz-15kHz with 80dB signal-to-noise. The 2U full-metal chassis measures 89 x 483 x 366mm at under 8kg, running from 200-240V AC with fuse protection and drawing under 15W.
| MIC Input | N.A |
|---|---|
| AUX Input | N.A |
| EMC Input | N.A |
| Monitor Channel | 10CH |
| Input | 100V/70V Audio Signal |
| Audible Monitor | 500mW, Full-range Loud speaker |
| Indicator | Power LED |
| Zone Speaker Out | N.A |
| Power Handling | N.A |
| Priority Contact Input | N.A |
| Alarm Output | N.A |
| Output | N.A |
| Muting Function | N.A |
| Frequency Response | 100Hz-15kHz |
| S/N Ratio | 80dB |
| THD | N.A |
| Tone Controls | Monitor Volume, Channel Select, Power Switch |
| Control | N.A |
| Power Input | 200-240V AC, Fuse Protection |
| Power Consumption | <15W |
| Mount | 2U 19" Rack Mount, Table Top |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 89(H) x 483(W) x 366(D) mm, <8Kg |
