SKU: AP-P24D
IP66-rated dual direction projection speaker with two 5-inch full-range woofers firing opposite ways, taps at 10W, 5W and 2.5W in a full metal enclosure.
The AP-P24D fires in two directions from one housing, which halves the hardware where coverage is needed both ways along a corridor, walkway or platform.
Two 5-inch full-range woofers give it 92dB sensitivity — slightly higher than the single-direction model — across 130Hz-17kHz with maximum output to 101dB.
Mounting one dual unit rather than two singles also halves the cable runs and the fixings, which matters on structures where every penetration is a waterproofing decision.
Taps are 10W, 5W and 2.5W on 70V or 100V line. The full metal enclosure with grille is IP66 rated with a waterproof cable tail gland, measuring 140mm diameter x 210mm at under 2.9kg in white, with a built-in wall bracket.
| Rated power output | 10W/5W/2.5W |
|---|---|
| Line input | 70V/100V LMT |
| SPL | 92dB at 1W/1M, Max. up to 101dB |
| Freq. response | 130Hz-17KHz |
| Speaker type | 5"x 2 full range woofer |
| Installation | Wall and Ceiling |
| Mount | Built in wall mount bracket |
| Enclosure | Full Metal Enclosure included grille |
| IP protection | IP66 |
| Connector | Waterproof Cable tail gland |
| Color | White |
| Product dimension | 140(D) x 210(H)mm |
| Weight | <2.9Kg |
