SKU: AP-NC120
120W RMS IP column speaker in a 1384mm aluminium enclosure, with a built-in Class D stereo amplifier and 16-bit DAC audio processor for long-throw outdoor coverage.
The AP-NC120 is the full-height column in the AVTRON IP range at nearly 1.4 metres, built for the distances that defeat smaller speakers: large forecourts, transport interchanges, stadium approaches and open industrial sites.
A Class D stereo amplifier and a 16-bit DAC digital audio processor are built into the column, so the signal stays digital until the last possible point — the reason a long cable run to this speaker does not degrade what comes out of it.
Networking covers TCP, UDP and IGMP with codec support across MP3, WMA and WAV at 8-512kbps. Response runs 130Hz-16kHz ±3dB, focused on speech intelligibility outdoors.
The white aluminium enclosure measures 1384 x 227 x 125mm at 12.5kg, takes a 24V DC supply, mounts to a column or wall, and operates from -30°C to 55°C.
| Rated power | RMS 120W |
|---|---|
| Power | DC-24V |
| Network port | RJ-45(10/100Mbps) |
| Network protocol | TCP,UDP,IGMP |
| Audio type | MP3/WMA/WAV |
| Audio bitrate | 8K-512Kbps |
| Frequency response | 130Hz - 16KHz(±3dB) |
| Dimension | 1384(H)x227(W)x125(D)mm |
| Working temp. | -30 ℃ ~ 55 ℃ |
| Installation | Column/Wall Mount Outdoor |
| Enclosure | Aluminum, White finish |
| Weight | 12.5kg |
