SKU: AP-N8A120
120W Class D network mixer amplifier with a built-in audio controller, three microphone inputs, 100V line output and alarm I/O, designed for multi-room sites.
The AP-N8A120 suits the multi-room building — a warehouse with an office block, a school wing, a medium hospital department — where several zones share one amplifier but the site still needs network paging.
Three microphone inputs, two auxiliary and one line input handle local sources, while the built-in audio controller receives paging and scheduled programme from the IP PA system without a separate decoder.
The 144 x 32 LCD gives a status read at the rack, and 0V alarm input and output integrate the amplifier with fire panels and building systems. Class D efficiency holds consumption under 150W for 120W of output.
Speaker output is 100V line, signal-to-noise better than 90dB across 20Hz-16kHz. The 1U full-metal chassis measures 44 x 483 x 408mm at under 12kg, running from 200-240V or 110V AC with fuse protection.
| Rated Power Out | 120W |
|---|---|
| Audio Input | 3x MIC, 2x Aux, 1x Line In |
| Audio Output | 1x Line Out, 100V Line |
| Display Screen | LCD type 144x32 |
| Network Protocol | TCP,UDP,IGMP,ICMP,ARP |
| Network Port | RJ-45(10/100Mbps) |
| Audio Compression | ADPCM,MP3, MP2, PCM |
| Audio Bitrate & Sampling | 8kHz～44.1kHz, 16bit, 8kbps-320kbps |
| Audio Delay | <105 ms(millisecond) |
| S/N Ratio | >90dB, 20Hz-16KHz |
| Alarm | 1x 0V Alarm In, 1x 0V Alarm Out |
| Power Input | 200-240V AC or 110V AC, Fuse Protection |
| Power Consumption | <150W |
| Working Temp. & Humidity | -10 ℃ ~ 50 ℃, ≤ 90%RH (Not Condensing) |
| Mount | 1U 19" Rack Mount, Table Top |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 44(H) x 483(W) x 408(D) mm, <12Kg |
