SKU: AP-N9E15W
Compact 2 x 15W network amplifier powered over PoE, driving speakers directly from a LAN or WAN connection with under 100ms audio delay.
The AP-N9E15W puts amplification at the speaker rather than in a rack. Power over Ethernet means one cable delivers both audio and power, so a small zone can be added to an IP PA system wherever there is a network drop — no local mains, no speaker cable back to a plant room.
An ARM and DSP processor handles decoding across ADPCM, MP3, MP2, PCM, WMA and WAV at 8kHz to 44.1kHz, holding delay under 100ms so announcements stay in step with adjacent zones. Signal-to-noise is 90dB or better across 20Hz-22kHz.
Two 15W outputs drive speakers directly, with an additional line output for feeding an external amplifier where a zone later grows. It runs over LAN or WAN through standard gateways and routers on TCP, UDP, IGMP, ICMP, ARP and DNS.
The full-metal black chassis is 30 x 100 x 70mm at under 0.7kg, wall-mounted or sitting on a desk, powered from PoE or 12-24V DC.
| Power out | 2 x 15W |
|---|---|
| Audio output | 1 Audio out, 1 Speaker out |
| Volume control | Yes |
| Network protocol | TCP,UDP,IGMP,ICMP,ARP, DNS |
| Network speed | RJ-45(10/100Mbps) |
| Audio compression | ADPCM,MP3, MP2, PCM, WMA,WAV |
| Audio bitrate | 8kHz-44.1kHz |
| Audio delay | <100 ms |
| S/N ratio | ≥90dB |
| Frequency | 20Hz-22KHz |
| Power Input | DC 12V-24V or POE |
| Mount | Wall mount or Table top |
| Working temp. & Humidity | -0 ℃ ~ 50 ℃, ≤ 90%RH (Not Condensing) |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 30(H) x 100(W) x 70(D) mm, <0.7Kg |
