SKU: AP-EW15P
Two-way PoE network wall speaker with a 5-inch woofer and 1.5-inch tweeter, built-in Class D amplifier and decoder, mounting on an aluminium U-bracket.
The AP-EW15P is the wall-mount member of the AVTRON PoE speaker family, for rooms where there is no ceiling void to work with — exposed-services fit-outs, warehouses, corridors with solid soffits.
A genuine two-way design with a 5-inch woofer and 1.5-inch tweeter gives it more range than the single-driver units in this class, which matters when the same speaker carries both speech and background music.
Network decoding and a 15W RMS Class D amplifier (20W peak) are built in, powered over 802.3af or 802.3at, with 12V DC as an alternative. Speakers group or address individually from the server.
Sensitivity is 92dB at 1W/1M across 100Hz-18kHz ±3dB, distortion at or under 1%, signal-to-noise 85dB or better. The UV-protected ABS body with black or white metal grille measures 170 x 260 x 190mm at under 2.8kg, rated -30°C to 55°C.
| Rated power | 15Watts RMS |
|---|---|
| Built-in amplifier | 15W RMS & Max. 20W |
| Speaker type | Two-Way 5"woofer + 1.5" tweeter |
| Power | DC-12V, POE 802.3af or POE 802.3at |
| Cutout size | N.A |
| Dimension | N.A |
| SPL | 92dB at 1W/1M |
| Network port | RJ-45(10/100Mbps) |
| Network protocol | TCP, UDP, IGMP, ARP, ICMP |
| Audio type | MP3, MP2 |
| Audio bitrate | 8K-512Kbps |
| Frequency response | 100Hz-18KHz(±3dB) |
| THD | ≤1% |
| S/N ratio | ≥85dB |
| Working temp. | 170(H) x 260(W) x 190(D)mm |
| Installation | -30 ℃ ~ 55 ℃ |
| Enclosure | Wall mount, U-shaped bracket(aluminum) |
| Color | ABS plastic(UV-protected), Metal grille(black or white) |
| Weight | <2.8Kg |
