SKU: AP-Z218
16 zone speaker selector with four audio inputs arranged as a 4x4 matrix with priority override, handling 375W per channel to a total capacity of 1.5kW.
The AP-Z218 does more than route one amplifier to many zones — its 4x4 matrix lets four separate programme sources reach four groups of four zones independently, so different parts of a building can carry different audio at the same time.
A fifth priority channel overrides all of it when an emergency or paging signal arrives, with priority contact inputs on all 16 zones activated by a 0V trigger.
That combination suits venues where a retail floor, a restaurant, an office wing and a back-of-house area each want their own programme but must all be reachable by one announcement.
Inputs take 100V or 70V audio, handling 375W per channel with a total capacity of 1.5kW. An alarm output provides a 0V trigger signal to downstream equipment. Control is by 16 zone push buttons and a power switch. The 2U full-metal chassis runs from 200-240V AC with fuse protection at under 20W.
| MIC Input | N.A |
|---|---|
| AUX Input | N.A |
| EMC Input | N.A |
| Monitor Channel | N.A |
| Input | 4 program and 1 Priority Channel, 100V/70V Audio Signal |
| Audible Monitor | N.A |
| Indicator | N.A |
| Zone Speaker Out | 16 Zone, Divided in 4 groups X 4 Zone each |
| Power Handling | 375W/per channel, Total Capacity 1.5KW |
| Priority Contact Input | 16 Zone, Activated by 0V Trigger Signal |
| Alarm Output | 0V Trigger Signal |
| Output | N.A |
| Muting Function | N.A |
| Frequency Response | N.A |
| S/N Ratio | N.A |
| THD | N.A |
| Tone Controls | N.A |
| Control | 16 Zone Push button, 1 Power Switch |
| Power Input | 200-240V AC, Fuse Protection |
| Power Consumption | <20W |
| Mount | 2U 19" Rack Mount, Table Top |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 89(H) x 483(W) x 366(D) mm, <8Kg |
