SKU: AP-D824EV
Eight zone EVAC voice alarm controller with a 240W Class D amplifier, supervised A/B speaker lines per zone, 255 stored messages and programmable control I/O.
The AP-D824EV is the eight zone version of AVTRON's 240W voice alarm controller, for buildings whose evacuation strategy needs more zones than a six zone unit provides — typically multi-storey premises where each floor is its own zone.
All eight zones carry A and B speaker lines with low impedance monitoring, so speaker circuit faults surface through supervision rather than during an incident.
Storage holds up to 255 MP3 or WMA messages on SD card. Eight programmable control inputs and eight programmable outputs, plus fault, EVAC and reset contacts, connect the controller to fire detection and building systems.
The log retains 1000 records over ten years. Inputs include balanced mic/line, RCA and a fireman's microphone; speaker output is 100V across A/B eight zone lines at 80Hz-20kHz. Power is 200-260V AC with 24V DC backup at 300W.
| Rated Power Output | 240W |
|---|---|
| Inputs 1, 2 | 390mV, 10kΩ, MIC/Line In, Balanced |
| Inputs 3 ~ 6 | 350mV, 10kΩ, RCA |
| Frequency Response | 80Hz ~ 20kHz |
| Rec Out | 200mV |
| Speaker Output | 100V, AB 8 Zone Speaker Out |
| Fireman Microphone | 5mv, 600Ω |
| S/N Ratio | >70dB |
| THD | <1%, 1KHz |
| Control Input | 8 programmable Max 3.3V(voltage mode) or 0V closed contact |
| Control Output | 8 programmable 0V closed contact, Fault & EVAC 0V closed contact, Reset Input 0V closed contact |
| Voice Record message | MP3/WMA format, max 255 message, In SD-Card or by Player |
| Log Record | Last 10 years up to 1000 records |
| Power Input | 200-260V AC, 24V DC, Fuse Protection(Optional 115V) |
| Power Consumption | 300W |
| Working Temp. & Humidity | -5 ℃ ~ 40 ℃, ≤ 95%RH (Not condensing) |
| Mount | 19" Rack Mount, Table Top |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 132(H) x 483(W) x 450(D) mm, <21Kg |
