SKU: AP-N8A240
240W Class D network mixer amplifier combining local mixing, IP paging and 100V line distribution with alarm I/O, in a 1U 19-inch chassis.
The AP-N8A240 doubles the output of the 120W model while keeping the same 1U footprint, which is the practical constraint in most comms cabinets. It covers larger warehouses, full school blocks and hospital floors running substantial speaker loads.
Local sources connect through three microphone, two auxiliary and one line input; network audio arrives via the built-in controller, so paging and scheduled programme need no additional rack hardware.
0V alarm input and output link the amplifier to fire and building management systems, and the 144 x 32 LCD reports state without a laptop. Class D operation keeps draw under 280W at full 240W output.
100V line output feeds distributed speakers with signal-to-noise better than 90dB over 20Hz-16kHz. The full-metal chassis is 44 x 483 x 408mm at under 14kg on 200-240V or 110V AC.
| Rated Power Out | 240W |
|---|---|
| Audio Input | 3x MIC, 2x Aux, 1x Line In |
| Audio Output | 1x Line Out, 100V Line |
| Display Screen | LCD type 144x32 |
| Network Protocol | TCP,UDP,IGMP,ICMP,ARP |
| Network Port | RJ-45(10/100Mbps) |
| Audio Compression | ADPCM,MP3, MP2, PCM |
| Audio Bitrate & Sampling | 8kHz～44.1kHz, 16bit, 8kbps-320kbps |
| Audio Delay | <105 ms(millisecond) |
| S/N Ratio | >90dB, 20Hz-16KHz |
| Alarm | 1x 0V Alarm In, 1x 0V Alarm Out |
| Power Input | 200-240V AC or 110V AC, Fuse Protection |
| Power Consumption | <280W |
| Working Temp. & Humidity | -10 ℃ ~ 50 ℃, ≤ 90%RH (Not Condensing) |
| Mount | 1U 19" Rack Mount, Table Top |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 44(H) x 483(W) x 408(D) mm, <14Kg |
