SKU: AP-N9EC240
240W network mixer power amplifier with 100V, 70V and 8 ohm outputs, on-board network audio decoding and an LCD status display in a 2U rack chassis.
The AP-N9EC240 sits in the middle of the AP-N9EC series, matched to zones that have outgrown a 120W tap — a full school block, a hospital ward group, a mid-sized industrial building.
Speaker outputs cover 100V and 70V line as well as 8 ohm, so a single amplifier model serves both new distributed installations and legacy low-impedance runs found in older buildings.
Three microphone and two line inputs feed the mixer; network paging and scheduled programme decode on board across ADPCM, MP3, MP2 and PCM with delay under 100ms. The 144 x 32 LCD gives local status without a laptop.
Distortion stays at or under 0.3% with signal-to-noise of 85dB or better across 20Hz-16kHz. The 2U chassis is 88 x 483 x 370mm at under 14kg, drawing 350W from 200-240V AC.
| Rated Power Out | 240W |
|---|---|
| Audio Input | 3 MIC in, 2 Line in |
| Audio Output | 1 Line out |
| Speaker out | 100V/70V, 8 Ohms |
| Display Screen | LCD type 144x32 |
| Network protocol | TCP,UDP,IGMP,DNS |
| Network Port | RJ-45(10/100Mbps) |
| Audio Compression | ADPCM,MP3, MP2, PCM |
| Audio bitrate | 8kHz～44.1kHz |
| Audio Delay | <100 ms (millisecond) |
| S/N Ratio | ≥85dB |
| Frequency response | 20Hz-16KHz |
| THD | ≤0.3% |
| Power Input | 200-240V AC, 50-60Hz |
| Power Consumption | 350W |
| Working Temp. & Humidity | -5 ℃ ~ 40 ℃, ≤ 90%RH (Not Condensing) |
| Mount | 19" Rack mount, Table top |
| Enclosure & Color | Full metal, Black |
| Dimension & Weight | 88(H) x 483(W) x 370(D) mm, <14Kg |
