SKU: AP-NW30
The AP-NW30 is a network audio endpoint in wall speaker form: IP decoding, Class D amplification and a 5-inch two-way driver in one unit, fed by a single Cat cable.
IEEE 802.3at PoE carries power, audio and control together, so adding a zone means patching a switch port. Support for up to 1,200 zones allows multi-group and multi-zone configurations broadcasting different content simultaneously.
Volume is adjustable over the network rather than at the speaker, which matters on ceilings and high walls where physical access means a ladder. Paging prioritisation ensures announcements displace background music automatically.
A 12V DC backup power input keeps the speaker live through a mains or PoE failure — important where the system doubles as voice alarm. It suits schools, offices, malls and large facilities.
| Rated Power | 30W |
|---|---|
| Power Input | DC 12V(optional DC 24V) |
| Network Port | RJ-45(10/100Mbps) |
| SPL | 100dB at 1W/1M |
| Network Protocol | TCP,UDP |
| Audio Compression | MP3, WMA, WAV |
| Audio Bitrate & Sampling | 8kHz-45kHz, 16bit, 8K-320Kbps |
| Frequency Response | 80-20KHz (±3dB) |
| S/N Ratio | >90dB 190Hz-18KHz |
| Installation | Wall Mount, Hanging |
| Enclosure | ABS Plastic |
| IP Protection | IP55 |
| Dimension | 155(L) x 195(W) x 295(H) mm |
| Color | White |
