SKU: AP-N8A350
350W Class D network mixer amplifier with built-in audio controller, six inputs, 100V line output and alarm I/O in a 1U rack chassis under 14kg.
The AP-N8A350 carries the speaker loads that defeat smaller amplifiers: long warehouse runs, multi-level car parks, large manufacturing floors where horn and cabinet speakers are spread across a wide area.
Despite 350W of Class D output it stays in a 1U chassis at under 14kg, which keeps rack space and structural loading reasonable in a comms room that also holds switching and recording gear.
Local mixing runs from three microphone, two auxiliary and one line input, with the network audio controller built in. 0V alarm input and output tie into fire and building systems, and the 144 x 32 LCD shows status at the rack.
Output is 100V line with signal-to-noise of 90dB or better across 20Hz-16kHz, drawing under 500W from a 200-240V or 110V AC supply with fuse protection.
| Rated Power Out | 350W |
|---|---|
| Audio Input | 3x MIC, 2x Aux, 1x Line In |
| Audio Output | 1x Line Out, 100V Line |
| Display Screen | LCD type 144x32 |
| Network Protocol | TCP,UDP,IGMP,ICMP,ARP |
| Network Port | RJ-45(10/100Mbps) |
| Audio Compression | ADPCM,MP3, MP2, PCM |
| Audio Bitrate & Sampling | 8kHz～44.1kHz, 16bit, 8kbps-320kbps |
| Audio Delay | <105 ms(millisecond) |
| S/N Ratio | ≥90dB, 20Hz-16KHz |
| Alarm | 1x 0V Alarm In, 1x 0V Alarm Out |
| Power Input | 200-240V AC or 110V AC, Fuse Protection |
| Power Consumption | <500W |
| Working Temp. & Humidity | -10 ℃ ~ 50 ℃, ≤ 90%RH (Not Condensing) |
| Mount | 1U 19" Rack Mount, Table Top |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 44(H) x 483(W) x 408(D) mm, <14Kg |
