SKU: AP-SC40
40W outdoor SIP column speaker in a 520mm aluminium enclosure, powered by PoE or 24V DC, registering to a phone system for direct-dial paging.
The AP-SC40 brings column-speaker directivity to SIP systems. At 520mm it suits entrances, walkways and courtyards where speech needs to carry along a space without washing off hard surfaces.
The speaker registers to the phone system as a SIP endpoint, so it can be dialled individually or paged as part of a group, using the dial plan already in place.
Power comes from PoE or a 24V DC feed, with decoding and amplification built into the column. Audio handles MP3, WMA and WAV at 8-512kbps across 130Hz-16kHz ±3dB.
The white aluminium enclosure measures 520 x 227 x 125mm at 5kg for column or wall mounting outdoors, rated -30°C to 55°C.
| Rated power | RMS 40W |
|---|---|
| Built-in amplifier | N.A |
| Network protocol | TCP,UDP,IGMP |
| Speaker type | N.A |
| Power | DC-24V/PoE |
| Cutout size | N.A |
| Dimension | 520(H)X227(W)X125(D)mm |
| SPL | N.A |
| Network port | RJ-45(10/100Mbps) |
| Audio type | MP3/WMA/WAV |
| Audio bitrate | 8K-512Kbps |
| Frequency response | 130Hz - 16KHz(±3dB) |
| THD | N.A |
| S/N ratio | N.A |
| Working temp. | -30 ℃ ~ 55 ℃ |
| Installation | Column/Wall mount outdoor |
| Enclosure | Aluminum, White finish |
| Color | N.A |
| Weight | 5kg |
