SKU: AP-D850EV
Eight zone EVAC voice alarm controller with a 500W Class D amplifier, supervised A/B speaker lines, 255 stored messages and a ten year event log.
The AP-D850EV is the largest voice alarm controller in AVTRON's EVAC digital range, combining eight supervised zones with 500W of Class D amplification.
It suits multi-storey and high-occupancy buildings where both zone count and speaker load are substantial — hospitals, large schools, shopping centres and transport facilities.
All eight zones run A and B speaker lines with low impedance monitoring for continuous circuit supervision. Up to 255 MP3 or WMA messages are stored on SD card for staged and zone-specific evacuation announcements.
Eight programmable control inputs and outputs plus fault, EVAC and reset contacts integrate with fire detection. The log holds 1000 records across ten years. Inputs cover balanced mic/line, RCA and a fireman's microphone, with 100V speaker output at 80Hz-20kHz. Power is 200-260V AC with 24V DC backup at 550W.
| Rated Power Output | 500W |
|---|---|
| Inputs 1, 2 | 390mV, 10kΩ, MIC/Line In, Balanced |
| Inputs 3 ~ 6 | 350mV, 10kΩ, RCA |
| Frequency Response | 80Hz ~ 20kHz |
| Rec Out | 200mV |
| Speaker Output | 100V, AB 6 Zone Speaker Out |
| Fireman Microphone | 5mv, 600Ω |
| S/N Ratio | >70dB |
| THD | <1%, 1KHz |
| Control Input | 8 programmable Max 3.3V(voltage mode) or 0V closed contact |
| Control Output | 8 programmable 0V closed contact, Fault & EVAC 0V closed contact, Reset Input 0V closed contact |
| Voice Record message | MP3/WMA format, max 255 message, In SD-Card or by Player |
| Log Record | Last 10 years up to 1000 records |
| Power Input | 200-260V AC, 24V DC, Fuse Protection(Optional 115V) |
| Power Consumption | 550W |
| Working Temp. & Humidity | -5 ℃ ~ 40 ℃, ≤ 95%RH (Not condensing) |
| Mount | 19" Rack Mount, Table Top |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 132(H) x 483(W) x 450(D) mm, <21Kg132(H) x 483(W) x 450(D) mm, <21Kg |
