SKU: AP-N8A500
500W Class D network mixer amplifier, the highest output in the AP-N8A range, with built-in IP audio control, 100V line distribution and alarm I/O in 1U.
The AP-N8A500 is the top of the AP-N8A range, for sites where a single zone or amplifier group draws serious power — stadium concourses, large distribution centres, industrial sites with dozens of horn speakers.
It keeps the same 1U format and control layout as the smaller models in the family, so a site can standardise on one amplifier design and vary only the rating per zone. Three microphone, two auxiliary and one line input feed the mixer; the network controller is built in.
0V alarm input and output allow integration with fire detection and building management, while the 144 x 32 LCD provides local status. Consumption stays under 700W for 500W of Class D output.
100V line output drives distributed speakers at better than 90dB signal-to-noise across 20Hz-16kHz. The chassis is 44 x 483 x 408mm at under 16kg on 200-240V or 110V AC.
| Rated Power Out | 500W |
|---|---|
| Audio Input | 3x MIC, 2x Aux, 1x Line In |
| Audio Output | 1x Line Out, 100V Line |
| Display Screen | LCD type 144x32 |
| Network Protocol | TCP,UDP,IGMP,ICMP,ARP |
| Network Port | RJ-45(10/100Mbps) |
| Audio Compression | ADPCM,MP3, MP2, PCM |
| Audio Bitrate & Sampling | 8kHz～44.1kHz, 16bit, 8kbps-320kbps |
| Audio Delay | <105 ms(millisecond) |
| S/N Ratio | ≥90dB, 20Hz-16KHz |
| Alarm | 1x 0V Alarm In, 1x 0V Alarm Out |
| Power Input | 200-240V AC or 110V AC, Fuse Protection |
| Power Consumption | <700W |
| Working Temp. & Humidity | -10 ℃ ~ 50 ℃, ≤ 90%RH (Not condensing) |
| Mount | 1U 19" Rack Mount, Table Top |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 44(H) x 483(W) x 408(D) mm, <16Kg |
