SKU: AP-D824RT
The AP-D824RT adds eight supervised zones with 240W of Class D amplification to an EVAC voice alarm system.
Eight zones per router rather than six means fewer units to reach a given zone count — worth considering on multi-storey buildings where zone counts climb quickly and rack space does not.
Each zone runs A and B speaker lines with low impedance monitoring, and routers cascade to a maximum system capacity of 120 zones with up to 32 remote paging microphones across the system.
It pairs with the AP-D824EV controller so output rating and zone structure stay consistent as the installation expands.
| Rated Power Output | 240W |
|---|---|
| Inputs 1, 2 | 390mV, 10kΩ, MIC/Line In, Balanced |
| Inputs 3 ~ 6 | 350mV, 10kΩ, RCA |
| Frequency Response | 80Hz ~ 20kHz |
| Rec Out | 200mV |
| Speaker Output | 100V, AB 8 Zone Speaker Out |
| Fireman Microphone | 5mv, 600Ω |
| S/N Ratio | >70dB |
| THD | <1%, 1KHz |
| Control Input | 8 programmable Max 3.3V(voltage mode) or 0V closed contact |
| Control Output | 8 programmable 0V closed contact, Fault & EVAC 0V closed contact, Reset Input 0V closed contact |
| Voice Record message | MP3/WMA format, max 255 message, In SD-Card or by Player |
| Log Record | Last 10 years up to 1000 records |
| Power Input | 200-260V AC, 24V DC, Fuse Protection(Optional 115V) |
| Power Consumption | 300W |
| Working Temp. & Humidity | -5 ℃ ~ 40 ℃, ≤ 95%RH (Not condensing) |
| Mount | 19" Rack Mount, Table Top |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 132(H) x 483(W) x 450(D) mm, <21Kg |
