SKU: AP-D850RT
Eight zone EVAC extension router with a 500W Class D amplifier, supervised A/B speaker lines, 255 stored messages and programmable control I/O, cascading to 120 zones.
The AP-D850RT is the highest-capacity extension router in the EVAC digital range, adding eight zones of 500W amplification to an existing voice alarm system.
Routers cascade to a total system capacity of 120 zones, letting a large estate expand on one architecture without replacing the control equipment.
Each zone runs A and B speaker lines with low impedance monitoring, and message storage holds up to 255 MP3 or WMA recordings on SD card or via the player.
Eight programmable control inputs and outputs, plus fault, EVAC and reset contacts, connect to fire and building systems, with a log retaining 1000 records over ten years. Speaker output is 100V across A/B eight zone lines at 80Hz-20kHz with signal-to-noise better than 70dB. Power is 200-260V AC with 24V DC backup at 550W.
| Rated Power Output | 500W |
|---|---|
| Inputs 1, 2 | 390mV, 10kΩ, MIC/Line In, Balanced |
| Inputs 3 ~ 6 | 350mV, 10kΩ, RCA |
| Frequency Response | 80Hz ~ 20kHz |
| Rec Out | 200mV |
| Speaker Output | 100V, AB 8 Zone Speaker Out |
| Fireman Microphone | 5mv, 600Ω |
| S/N Ratio | >70dB |
| THD | <1%, 1KHz |
| Control Input | 8 programmable Max 3.3V(voltage mode) or 0V closed contact |
| Control Output | 8 programmable 0V closed contact, Fault & EVAC 0V closed contact, Reset Input 0V closed contact |
| Voice Record message | MP3/WMA format, max 255 message, In SD-Card or by Player |
| Log Record | Last 10 years up to 1000 records |
| Power Input | 200-260V AC, 24V DC, Fuse Protection(Optional 115V) |
| Power Consumption | 550W |
| Working Temp. & Humidity | -5 ℃ ~ 40 ℃, ≤ 95%RH (Not condensing) |
| Mount | 19" Rack Mount, Table Top |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 132(H) x 483(W) x 450(D) mm, <21Kg |
