SKU: AP-D406
Emergency announcement panel producing an alarm siren or stored voice message automatically on an external trigger or a front panel button, with two recordable messages up to 180 seconds.
The AP-D406 is the emergency voice source in an analogue PA rack. A 0V short signal from a fire panel or a press of the front panel button starts the alarm immediately — either a generated siren tone or a stored voice message.
Two messages can be recorded into the built-in IC memory, up to 180 seconds total, so a site can hold both an evacuation and an all-clear or shelter-in-place announcement without external playback hardware.
Recording is done at the panel using the play/record controls, record level and volume, with a microphone input (600 ohm, 5mV) and a line input (10k ohm, 330mV).
The siren and message path runs 100Hz-3.4kHz ±3dB, tuned for cut-through, while the microphone and audio inputs cover 60Hz-16kHz. Distortion is under 0.1% at 1kHz with signal-to-noise better than 70dB. The 2U full-metal chassis runs from 200-240V AC with 24V DC and fuse protection at under 15W.
| MIC Input | 600ohms, 5mV, Unbalanced |
|---|---|
| Line Input | 10k ohms, 330mV, unbalanced |
| Output | 10K Ohms, 330mV(0dB), Siren or Recorded Message |
| Frequency Response | Alarm siren or record:100 Hz ~ 3.4k Hz (+ / - 3 dB), MIC input or audio input:60 Hz ~ 16k Hz (+ / - 3 dB) |
| Recorder | Built in IC, 2x Message, Max. 180 seconds |
| ADC/DAC Sampling frequency | 8KHz, 5-bit; 60 seconds |
| S/N Ratio | > 70dB |
| Alarm Activation | OV Short Signal |
| THD | Less than 0.1% at 1KHz |
| Tone Controls | Play/rec controls, volume, rec level and power |
| Power Input | 200-240V AC, Fuse Protection, 24V DC |
| Power Consumption | <15W |
| Mount | 2U 19" Rack Mount, Table Top |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 89(H) x 483(W) x 366(D) mm, <7Kg |
