SKU: AP-N9EGT
GSM integration unit with a SIM slot and 2.8-inch LCD, letting an authorised caller dial in and make a live announcement over the IP PA system from anywhere.
The AP-N9EGT gives a PA system a phone number. An authorised caller dials the SIM in the unit and speaks live over the site's speakers — useful when the person who needs to make the announcement is not on site, and essential when the network is down but the mobile network is not.
An ARM and DSP processor handles the audio path, and speakers or amplifiers connect directly to the unit. It operates over LAN or WAN through standard gateways and routers.
A 2.8-inch LCD shows call and system state at the rack. The single SIM slot takes a standard mobile service.
The full-metal black chassis measures 66 x 485 x 225mm at under 2.5kg, rack or table mounted, running from 200-240V AC with fuse protection.
| Sim card slot | 1 Port |
|---|---|
| Network protocol | TCP,UDP,IGMP,ICMP,ARP |
| Network port | RJ-45(10/100Mbps) |
| Screen | 2.8" LCD |
| Power input | 200-240V AC, Fuse Protection |
| Working temp. & Humidity | -10 ℃ ~ 50 ℃, ≤ 90%RH (Not Condensing) |
| Enclosure | 19" Rack mount, Table top, Full metal, Black |
| Dimension & Weight | 66(H) x 485(W) x 225(D) mm, <2.5Kg |
