SKU: AP-S9SOT
Weather-rated SIP calling terminal in a stainless steel outdoor housing, with built-in microphone and speaker for hands-free two-way intercom at a single button press.
The AP-S9SOT is the outdoor version of AVTRON's SIP intercom terminal, for gates, car park entries, yard access points and building frontages where a call point has to survive weather and handling.
A single button places a hands-free call to programmed SIP telephones and devices, with a two-button option where callers need a choice of destination. Built-in microphone and speaker carry full two-way conversation.
As a SIP endpoint it registers to the existing phone system, so after-hours diversion, escalation and call groups are configured with the tools the organisation already runs — no separate intercom management to maintain.
Audio covers MP3, WAV and G.711 at 8-32kHz 16-bit. The stainless steel outdoor housing measures 160 x 240 x 42mm at under 1kg, drawing under 500mA from 12V DC, rated 0°C to 60°C.
| Two-Way communication | Yes, Built-in MIC, Speaker |
|---|---|
| Network protocol | SIP,TCP,UDP,DNS,ARP,IGMP,ICMP |
| Network port | RJ-45(10/100Mbps) |
| Audio type | MP3/WAV/G.711 |
| Frequency/Sampling rate | 8kHz-32 kHz, 16 bit |
| Power | DC-12V, <500mV |
| Dimension | 160(W) x 240(D) x 42(H)mm |
| Working temp. | 0 ℃ ~ 60 ℃ |
| Enclosure | Stainless steel, Outdoor |
| Weight | <1Kg |
