SKU: AP-D405
Rack-mount telephone interface that answers an incoming call automatically and broadcasts the caller's voice over the PA system, to all zones or a selected zone.
The AP-D405 turns any telephone into a paging microphone. An incoming call on the RJ-11 line is answered automatically after a set number of rings, and the caller's voice is broadcast over the public address system.
Zone targeting means the call can go to the whole site or to a single area, so a manager off site can address one loading dock without disturbing the rest of the building.
A built-in stereo full-range monitor speaker (over 100mW) lets rack-side staff hear what is being broadcast. Ring times are configurable from two to five before answer, which prevents wrong numbers being put over the speakers.
Inputs are one RJ-11 and one microphone (400-775mV); outputs cover audio at 10mV-330V and an active 0V short circuit signal. The 2U full-metal chassis is 89 x 483 x 350mm at under 6kg, on 220-240V AC with 24V DC and fuse protection, drawing under 15W.
| Monitor Channel | N.A |
|---|---|
| Input | 1x RJ-11 connector, 1x MIC(400-775mV(0dB)) |
| Output | Audio out 10mV-330V, Active out 0V short circuit signal |
| Phone Monitor | Built-in stereo HiFi full range speaker, power>100mW |
| Ring Times | 2-5 times |
| Trigger Out | N.A |
| Audible Monitor | N.A |
| Tone Controls | N.A |
| Volume Level | N.A |
| S/N Ratio | N.A |
| Power Input | 220-240V AC, 24VDC, AC Fuse Protection |
| Power Consumption | <15W |
| Mount | 2U 19" Rack Mount, Table Top |
| Enclosure & Color | Full Metal, Black |
| Dimension & Weight | 89(H) x 483(W) x 350(D) mm, <6Kg |
