SKU: DS-KD-KK
Six-button nametag module for the KD8 modular door station, giving each resident a labelled call button with backlight compensation. IP65 rated.
The DS-KD-KK gives a small building six labelled call buttons — one per apartment, tenancy or department — so a visitor presses a name rather than remembering a number.
For a six-unit block or a small office building that is faster and less error-prone than a keypad or a scrolling display, and it needs no explanation to a first-time visitor or a delivery driver.
Backlight compensation behind the nametags keeps names legible after dark, which is when a badly lit door station generates most of its wrong calls.
The module is IP65 rated, measures 98.2 x 100.2 x 33.7mm, draws 2W or less, and operates from -40°C to 55°C. Multiple nametag modules can be combined for larger buildings.
| Processor | Embedded high performance processor |
|---|
| RS-485 | 1 |
|---|
| Button | 6 |
|---|---|
| Power consumption | ≤ 2 W |
| Installation | Flush mounting, surface mounting |
| Weight | Net weight: 190 g Gross weight: 438 g |
| Protective level | IP65 |
| Working temperature | -40 °C to 55 °C (-40 °F to 131 °F) |
| Working humidity | 10% to 95% |
| Dimension (W × H × D) | 98.2 mm × 100.2 mm × 33.7 mm (3.87" × 3.95" × 1.33") |
