SKU: DS-KH6320Y-WTE2
2-Wire indoor station with a 7-inch IPS touch screen at 1024 x 600, Wi-Fi and Hik-Connect app control, carrying IP intercom over two-core cable. Black finish.
The DS-KH6320Y-WTE2 runs a full IP intercom over ordinary two-core cable, which is what makes it the answer for retrofits.
Older buildings already have two-wire runs from an existing analogue intercom. Replacing that cabling with Cat6 through occupied apartments is disruptive and often impossible; this station reuses what is there and still delivers IP features, app control and video.
The 7-inch IPS touch screen at 1024 x 600 gives wider viewing angles than a standard TFT, which matters on a wall-mounted panel viewed from an angle rather than head-on.
Functionality matches the IP models: Hik-Connect app control for remote answering and door release, live view of door stations and public-area cameras, voice messages when unanswered, alarm linkage and elevator access control.
Capacity is 200 pictures and 200 alarm records with a TF card, 16 linked indoor extensions, 17 IP doorphones and 16 linked cameras, with 2.4GHz Wi-Fi. Finished in black.
| Operation system | Embedded Linux operation system |
|---|---|
| ROM | 32 MB |
| RAM | 128 MB |
| Processor | Embedded processor |
| Screen size | 7-inch |
|---|---|
| Operation method | Capacitive touch screen |
| Type | TFT |
| Resolution | 1024 × 600 |
| Audio input | Built-in omnidirectional microphone |
|---|---|
| Audio compression standard | G.711 U、G.711 A、G.722.1 |
| Audio output | Buit-in loudspeaker |
| Audio compression bitrate | 64 Kps |
| Audio quality | Noise suppression and echo cancellation |
| Volume adjustment | Adjustable |
| Message capacity | 200 captured pictures (with TF card); 200 alarm records 2 MB RAM (without TF card) reserved for events |
|---|---|
| Notice capacity | 200 |
| Linked network camera capacity | 16 |
| Linked indoor extensions capacity | 16 |
| Linked doorphone capacity | 17 IP doorphones Max. |
| Network protocol | TCP/IP, SIP, RTSP |
|---|---|
| Wi-Fi | IEEE802.11b, IEEE802.11g, IEEE802.11n |
| Alarm input | 8-ch alarm inputs |
|---|---|
| RS-485 | 1 |
| TF card | Max to 128 G, SD 2.0 or lower version |
| Alarm output | 2 relays (30 V Max.) |
| Lock control | 2 relays, Max. to 30 VDC, 0.3 A |
| Two-Wire IP interface | 1 |
| Installation | Surface mounting |
|---|---|
| Working temperature | -10 °C to 50 °C (14 °F to 122 °F) |
| Working humidity | 10% to 90% (no-condensing) |
| Dimension (W × H × D) | 200 mm × 140 mm × 23.6 mm (7.87" × 5.51" × 0.93") |
| Power supply | Powered by KAD704Y or KAD706Y series distributor |
| Application environment | Indoor |
| Power consumption | ≤ 4 W |
| Language | English, Arabic, French, Russian, Spanish, Spanish (Latin America), Italian, German, Polish, Turkish, Portuguese, Portuguese (Brazil), Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese |
