SKU: DS-KH8381-WTE1-FLUSH
Flush-mount metal-bodied indoor station with a 7-inch IPS touch screen, a physical door release button, 802.3at PoE that also powers the lock, and RS-485, relay and TF interfaces.
The DS-KH8381-WTE1/Flush recesses into the wall with a metal front, which is why it gets specified in apartment lobbies and higher-end fit-outs where a surface-mounted plastic panel would look wrong.
A single physical button opens the door without waking the screen or navigating a menu — the action people perform most, made deliberate rather than buried.
IEEE802.3at PoE is the significant electrical difference: at up to 30W it powers both the station and an electric lock from the network cable, removing the separate lock supply a 802.3af station would need.
Interfaces are unusually complete for an indoor station — alarm inputs, RS-485, relay outputs and a TF card slot — so it can act as the wiring point for door hardware rather than just a display.
The 7-inch capacitive IPS runs 1024 x 600 with H.265 and H.264 video, 16 linked indoor extensions, elevator access control and Hik-Connect app control. Supports both flush and surface mounting; finished in black.
| Operation system | Embedded Linux operation system |
|---|---|
| ROM | 32 MB |
| RAM | 128 MB |
| Processor | Embedded high performance processor |
| Screen size | 7-inch |
|---|---|
| Operation method | Capacitive touch screen |
| Type | Colorful IPS |
| Resolution | 1024*600 |
| Video compression standard | H.265；H.264 |
|---|
| Audio input | 1 built-in omnidirectional microphone |
|---|---|
| Audio compression standard | G.711u、G.711a、Opus、AAC-LD、AAC-LC、G.726、G.722.1 |
| Audio output | 1 built-in loudspeaker |
| Audio compression bitrate | 16、32、64 Kps |
| Audio quality | Noise suppression and echo cancellation |
| Volume adjustment | Adjustable |
| Message capacity | TF card inserted: 200 captured pictures, 200 alarm records Without TF card: 2 MB RAM for picture storage; The storage number is decided by the picture size, 200 alarm records |
|---|---|
| Notice capacity | 200 |
| Linked network camera capacity | 16 |
| Linked indoor extensions capacity | 16 |
| Network protocol | TCP/IP, SIP, RTSP |
|---|---|
| Wi-Fi | WiFi 802.11b/g/n |
| Wireless network | 1 RJ-45 10/100Mbps self-adaptive |
| Alarm input | 8 |
|---|---|
| Network interface | 1 RJ-45 10/100 Mbps self-adaptive |
| RS-485 | 1 |
| TF card | Support TF card, up to 128 G |
| Lock control | 4 relays, Max. 30 VDC 1A |
| Power supply output | Max. 12 VDC 0.5 A |
| Debugging port | 1 |
| Relay | 4 |
| Button | 1 physical button(s) |
|---|---|
| Installation | Flush mounting, surface mounting, table mounting |
| Working temperature | -10 °C to 50 °C (14 °F to 122 °F) |
| Working humidity | 10% to 90% (no-condensing) |
| Dimension (W × H × D) | 180.4 mm × 128.4 mm × 21.8 mm (7.10" × 5.06" × 0.86") |
| Power supply | IEEE802.3at, Standard PoE,12 VDC, 1.5 A |
| Application environment | Indoor |
| Power consumption | ≤ 12 W |
| Language | English, Arabic, French, Russian, Spanish, Spanish (Latin America), Italian, German, Polish, Turkish, Portuguese, Portuguese (Brazil), Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese |
| Material | Die-cast integrated aluminum alloy casing |
