SKU: DS-KH6320-WTE-WHITE
White finish Pro Series indoor station with a 7-inch 1024 x 600 touch screen, Wi-Fi, Hik-Connect app control, alarm linkage and elevator access control.
The white version of the Pro Series 7-inch indoor station, for interiors where the black panel would sit awkwardly against light walls and joinery.
The whole intercom system is configured from this screen with a setup wizard, so a residential or small commercial installation needs no PC and no separate software.
Live view covers the door station and cameras in public areas, letting a resident check the lobby or car park before going down. Voice messages record when the station is unanswered, and alarm linkage notifies a monitoring centre.
Elevator access control ties the intercom into lift calling for multi-storey buildings.
The 7-inch capacitive TFT runs 1024 x 600. Capacity is 200 pictures and 200 alarm records with a TF card, 16 linked indoor extensions, 17 linked doorphones and 16 linked cameras over TCP/IP, SIP and RTSP with Hik-Connect app control.
| Operation system | Linux |
|---|---|
| ROM | 32 MB |
| RAM | 128 MB |
| Processor | Embeded high performance processor |
| Screen size | 7-inch |
|---|---|
| Operation method | Capacitive touch screen |
| Type | Colorful TFT |
| Resolution | 1024 × 600 |
| Audio input | 1 built-in omnidirectional microphone |
|---|---|
| Audio compression standard | G.711 U、G.711 A、G.722.1 |
| Audio output | 1 built-in loudspeaker |
| Audio compression bitrate | 64 Kbps |
| Audio quality | Noise suppression and echo cancellation |
| Volume adjustment | Adjustable |
| Message capacity | TF card inser ted: 200 captured pictures, 200 alarm records Without TF card: 2 MB RAM for picture storage; The storage number is decided by the picture size, 200 alarm records |
|---|---|
| Notice capacity | 200 |
| Linked indoor extensions capacity | 16 |
| Linked doorphone capacity | 17 |
| Linked network camera capacity | 16 |
| Network protocol | TCP/IP, SIP, RTSP |
|---|---|
| Wi-Fi | 2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n |
| Alarm input | 8 |
|---|---|
| Network interface | 1 RJ-45 10/100 Mbps self-adaptive |
| RS-485 | 1 RS-485 (Half duplex) |
| TF card | Support TF card, up to 128 G |
| Alarm output | 2 relays, Max. 30 VDC 0.3 A |
| Installation | Surface mounting |
|---|---|
| Working temperature | -10 °C to 50 °C (14 °F to 122 °F) |
| Working humidity | 10% to 90% (no-condensing) |
| Dimension (W × H × D) | 200 mm × 140 mm × 15.1 mm (7.9" × 5.5" × 0.6") |
| Application environment | Indoor |
| Power consumption | ≤ 5 W |
| Language | English, Arabic, French, Russian, Spanish, Spanish (Latin America), Italian, German, Polish, Turkish, Portuguese, Portuguese (Brazil), Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese |
