SKU: DS-KD-ACW2
Aviation aluminium surface mounting bracket for two KD8 door station modules, including two module frames, two front panels, a button cover and fixings.
The DS-KD-ACW2 surface-mounts a two-module door station without any cavity work — main camera module plus a keypad, display or nametag module in one frame.
The kit is complete: two module frames, two front panels, a button cover and the necessary accessories.
Aviation aluminium keeps weight to 420g, which matters when the bracket is being held in position against a wall while the first fixings go in.
The cover measures 219 x 107 x 4mm with the installation frame at 219 x 107 x 32.7mm, rated -40°C to 55°C at 10% to 95% humidity.
| 660 g (with packaging) | |
| Working temperature | 40° C to +55° C(-40° F to 131° F) |
| Working humidity | 10% to 95% |
| Dimensions | Cover: 219 × 107 × 4 mm(8.62" × 4.21" ×0.16") |
| Material | Aviation Aluminum |
